Examination of Extraordinary Transmission of Waves Propagation through Gaps of Vertical Thin Barriers in Channels by A Hypersingular Boundary Element Method
Bin TENG, Jin HUANG
2019, 33(5): 509-521. doi: 10.1007/s13344-019-0049-x
[Abstract](1676) [FullText HTML] (383)
Abstract:
The extraordinary transmission (ET) phenomenon is examined for waves propagating through gaps of vertical thin barriers in channels with a hypersingular boundary element method model on the linear potential theory, and an estimate formula based on small gap approximation for predicting the number of ET frequencies is proposed. Numerical computations are carried out to examine the influences of barrier number, barrier interval, gap size, gap position and barrier arrangement on extraordinary transmission and wave height in the channel. It shows that all of those factors evidently affect the extraordinary transmission frequencies. The contours of wave amplitude show that very high waves can be excited in the basins between barriers at the extraordinary transmission frequencies. Proper arrangement of barriers in a channel can avoid the occurrence of ET phenomenon and reduce wave height in the channel.
Numerical and Experimental Study of Blockage Effect Correction Method in Towing Tank
Chun-yu GUO, Pei XU, Chao WANG, Zi KAN
2019, 33(5): 522-536. doi: 10.1007/s13344-019-0050-4
[Abstract](2142) [FullText HTML] (441)
Abstract:
When a ship model test is performed in a tank, particularly when the tank is small and the ship model is relatively large, the blockage effect will inevitably occur. With increased ship model scale and speed, the blockage effect becomes more obvious and must be corrected. In this study, the KRISO 3600 TEU Container Ship (KCS) is taken as a model and computational fluid dynamics techniques and ship resistance tests are applied to explore the mechanism and correction method of the blockage effect. By considering the degrees of freedom of the sinkage and trim, the resistance of the ship model is calculated in the infinite domain and for blockage ratios of 1.5%, 1.8%, 2.2%, and 3.0%. Through analysis of the free surface, pressure distribution, and flow field around the ship model, the action law of the blockage effect is studied. The Scott formula and mean flow correction formula based on the average cross sectional area are recommended as the main correction methods, and these formulas are improved using a factor for the return flow velocity correction based on comparison of the modified results given by different formulas. This modification method is verified by resistance test data obtained from three ship models with different scale ratios.
Taylor Dispersion of Contaminants by Dual-peak Spectral Random Waves
Guo-xing HUANG, Wing-Keung LAW Adrian, Xiao-meng GUO
2019, 33(5): 537-543. doi: 10.1007/s13344-019-0051-3
[Abstract](1757) [FullText HTML] (374)
Abstract:
Recent extensive and important studies have provided detailed information and compelling evidence on how the presence of waves influences the vertical diffusivity/dispersivity in the coastal environment, which can affect various water quality considerations such as the distribution of suspended sediments in the water column as well as the potential of eutrophication. Comparatively, how the presence of waves influences the horizontal diffusivity/dispersivity has received only scant attention in the literature. Our previous works investigated the role played by the Taylor mechanism due to the wave-induced drift profile which leads to the longitudinal dispersion of contaminants in the horizontal direction, under regular sinusoidal waves and random waves with single-peak spectra. Natural waves in the coastal environment, however, often possess dual-peak spectra, comprising both higher frequency wind waves and lower frequency swells. In this study, the Taylor dispersion of contaminants under random waves with dual-peak spectra is examined through analytical derivation and numerical calculations. The effects of various dual-peak spectral parameters on the horizontal dispersion, including the proportion of lower frequency energy, peak frequency ratio and spectral shape parameter, are investigated. The results show that the relative energy distribution between the dual peaks has the most significant effect. Compared with single-peak spectra with equivalent energy, the Taylor dispersion with dual-peak spectra is stronger when the lower frequency is close to the peak frequency of the single-peak spectrum, and weaker with the higher frequency instead. Thus, it can be concluded that with a dual-peak wave spectrum, wind-dominated seas with higher frequency lead to stronger dispersion in the horizontal direction than swell-dominated seas with lower frequency.
An Analytical Solution for Nearshore Circulation Driven by Focused/Defocused Waves
Yu-mei DING, Fengyan SHI
2019, 33(5): 544-553. doi: 10.1007/s13344-019-0052-2
[Abstract](1613) [FullText HTML] (375)
Abstract:
An offshore shoal or bar refracts ocean surface waves and causes wave focusing/defocusing on the adjacent beach. Wave focal patterns characterized by alongshore variations in wave height, wave angle, and breaking location induce alongshore non-uniformities of wave setup and nearshore circulation, e.g., rip currents and alongshore currents, in the surfzone. A simplified analytic model for nearshore circulation generated by focused/defocused waves on a planar beach is developed and theoretical solutions are obtained using transport stream function and perturbations in alongshore distributions of wave height and wave angle at the breaker line. The analytic model suggests that alongshore currents are strongly affected by a pair of counter-rotating vortices generated shoreward of the wave focal zone. The vortices are persistent, and their strengths depend on the amplitudes of alongshore variations in wave height and wave angle. The alongshore gradient in wave height tends to intensify the vortices while the convergence of wave angle tends to weaken the vortices. Divergent flows associated with the vortices in the surfzone are intense, strengthening alongshore currents in the downstream of the wave focal zone and weakening alongshore currents or causing flows reversal in the upstream. Alongshore currents are modulated by rip currents associated with the wave focusing/defocusing patterns.
Experimental Study of Air Layer Drag Reduction with Bottom Cavity for A Bulk Carrier Ship Model
Hao WU, Yong-peng OU
2019, 33(5): 554-562. doi: 10.1007/s13344-019-0053-1
[Abstract](2112) [FullText HTML] (400)
Abstract:
Air lubrication by means of a bottom cavity is a promising method for ship drag reduction. The characteristics of the bottom cavity are sensitive to the flow field around the ship hull and the effect of drag reduction, especially the depth of the bottom cavity. In this study, a ship model experiment of a bulk carrier is conducted in a towing tank using the method of air layer drag reduction (ALDR) with different bottom cavity depths. The shape of the air layer is observed, and the changes in resistance are measured. The model experiments produce results of approximately 20% for the total drag reduction at the ship design speed for a 25-mm cavity continuously supplied with air at Cq = 0.224 in calm water, and the air layer covers the whole cavity when the air flow rate is suitable. In a regular head wave, the air layer is easily broken and reduces the drag reduction rate in short waves, particularly when λ/Lw1 is close to one; however, it still has a good drag reduction effect in the long waves.
Identification of Pitch Dynamics of An Autonomous Underwater Vehicle Using Sensor Fusion
Abtahi Seid Farhad, Alishahi Mohammad Mehdi, Yazdi Ehsan Azadi
2019, 33(5): 563-572. doi: 10.1007/s13344-019-0054-0
[Abstract](1441) [FullText HTML] (375)
Abstract:
This paper presents a method for identification of the hydrodynamic coefficients of the dive plane of an autonomous underwater vehicle. The proposed identification method uses the governing equations of motion to estimate the coefficients of the linear damping, added mass and inertia, cross flow drag and control. Parts of data required by the proposed identification method are not measured by the onboard instruments. Hence, an optimal fusion algorithm is devised which estimates the required data accurately with a high sampling rate. To excite the dive plane dynamics and obtain the required measurements, diving maneuvers should be performed. Hence, a reliable controller with satisfactory performance and stability is needed. A cascaded controller is designed based on the coefficients obtained using a semi-empirical method and its robustness to the uncertainties is verified by the μ-analysis method. The performance and accuracy of the identification and fusion algorithms are investigated through 6-DOF numerical simulations of a realistic autonomous underwater vehicle.
A Numerical and Experimental Study on the Hull-Propeller Interaction of A Long Range Autonomous Underwater Vehicle
Ya-xing WANG, Jin-fu LIU, Tie-jun LIU, Zhi-bin JIANG, Yuan-gui TANG, Cheng HUANG
2019, 33(5): 573-582. doi: 10.1007/s13344-019-0055-z
[Abstract](3729) [FullText HTML] (442)
Abstract:
Range is an important factor to the design of autonomous underwater vehicles (AUVs), while drag reduction efforts are pursued, the investigation of body-propeller interaction is another vital consideration. We present a numerical and experimental study of the hull-propeller interaction for deeply submerged underwater vehicles, using a proportional-integral- derivative (PID) controller method to estimate self-propulsion point in CFD environment. The hydrodynamic performance of hull and propeller at the balance state when the AUV sails at a fixed depth is investigated, using steady RANS solver of Star-CCM+. The proposed steady RANS solver takes only hours to reach a reasonable solution. It is more time efficient than unsteady simulations which takes days or weeks, as well as huge consumption of computing resources. Explorer 1000, a long range AUV developed by Shenyang Institute of Automation, Chinese Academy of Sciences, was studied as an object, and self-propulsion point, thrust deduction, wake fraction and hull efficiency were analyzed by using the proposed RANS method. Behind-hull performance of the selected propeller MAU4-40, as well as the hull-propeller interaction, was obtained from the computed hydrodynamic forces. The numerical results are in good qualitative and quantitative agreement with the experimental results obtained in the Qiandao Lake of Zhejiang province, China.
Multi-Behavior Fusion Based Potential Field Method for Path Planning of Unmanned Surface Vessel
Ming-yu FU, Sha-sha WANG, Yuan-hui WANG
2019, 33(5): 583-592. doi: 10.1007/s13344-019-0056-y
[Abstract](1560) [FullText HTML] (416)
Abstract:
The problem of the unmanned surface vessel (USV) path planning in static and dynamic obstacle environments is addressed in this paper. Multi-behavior fusion based potential field method is proposed, which contains three behaviors: goal-seeking, boundary-memory following and dynamic-obstacle avoidance. Then, different activation conditions are designed to determine the current behavior. Meanwhile, information on the positions, velocities and the equation of motion for obstacles are detected and calculated by sensor data. Besides, memory information is introduced into the boundary following behavior to enhance cognition capability for the obstacles, and avoid local minima problem caused by the potential field method. Finally, the results of theoretical analysis and simulation show that the collision-free path can be generated for USV within different obstacle environments, and further validated the performance and effectiveness of the presented strategy.
New Analytical Solutions for Time Fractional Benjamin–Ono Equation Arising Internal Waves in Deep Water
TASBOZAN Orkun
2019, 33(5): 593-600. doi: 10.1007/s13344-019-0057-x
[Abstract](1338) [FullText HTML] (392)
Abstract:
In this article, the author sets up the abundant traveling wave solutions for time fractional Benjamin–Ono equation which was introduced to describe internal waves in stratified fluids by using Jacobi elliptic function expansion method. The traveling wave solutions are expressed in terms of the hyperbolic functions, the trigonometric functions and the rational functions. It can be seen that the obtained results are found to be important for the statement of some physical demonstrations of problems in mathematical physics and ocean engineering. In ocean engineering Benjamin–Ono equations are generally used in computer simulation for the water waves in deep water and open seas.
Numerical Investigation of Run-ups on Cylinder in Steep Regular Wave
Xiang FAN, Jing-xin ZHANG, Hua LIU
2019, 33(5): 601-607. doi: 10.1007/s13344-019-0058-9
[Abstract](1621) [FullText HTML] (377)
Abstract:
The run-up on offshore structures induced by the steep regular wave is a highly nonlinear flow with a free surface. This article focuses on the investigation of the steep regular wave run-up on a single vertical cylinder by solving the Navier-Stokes equations. A numerical wave tank is established based on the open-source package to simulate the wave scattering induced by a vertical cylinder. The VOF method is applied to capture the large deformation and breaking of the free surface. The numerical model is validated by experimental results. The relative wave run-ups on the front face and the back face along the centerline of a cylinder are analyzed. The changes of the relative run-ups with the wave steepness, the relative diameter and the relative depth are studied. It is found that the relative run-ups on the front face and the back face of the cylinder depend mainly on the wave steepness and the relative diameter, while the dependence on the relative depth is weak. The empirical formulae are proposed to calculate the relative run-ups in terms of the wave steepness of incident regular waves and the relative diameter of a cylinder.
Study on Nonlinear Characteristics of Freak-Wave Forces with Different Wave Steepness
Yan-fei DENG, Xin-liang TIAN, Xin LI
2019, 33(5): 608-617. doi: 10.1007/s13344-019-0059-8
[Abstract](1448) [FullText HTML] (409)
Abstract:
The nonlinear wave forces on vertical cylinders induced by freak wave trains were experimentally investigated. A series of freak wave trains with different wave steepness were modeled in a wave flume. The corresponding wave forces on vertical cylinders of different diameters were measured. The experimental wave forces were also compared with the predicted results based on Morison formula. Particular attentions were paid to the effects of wave steepness on the dimensionless peak forces, asymmetry characteristics of the impact forces and high-frequency force components. Wavelet-based analysis methods were employed in revealing the local energy structures and quadratic phase coupling in the freak wave forces.
Research of Power Take-off System for “Sharp Eagle II” Wave Energy Converter
Yin YE, Kun-lin WANG, Ya-ge YOU, Song-wei SHENG
2019, 33(5): 618-627. doi: 10.1007/s13344-019-0060-2
[Abstract](1881) [FullText HTML] (438)
Abstract:
The " Sharp Eagle” device is a wave energy converter of a hinged double floating body. The wave-absorbing floating body hinges on the semi-submerged floating body structure. Under the action of wave, the wave-absorbing floating body rotates around the hinge point, and the wave energy can be converted into kinetic energy. In this paper, the power take-off system of " Sharp Eagle II” wave energy converter (the second generation of " Sharp Eagle”) was studied, which adopts the hydraulic type power take-off system. The 0−1 power generation mode was applied in this system to make the " Sharp Eagle II” operate under various wave conditions. The principle of power generation was introduced in detail, and the power take-off system was simulated. Three groups of different movement period inputs were used to simulate three kinds of wave conditions, and the simulation results were obtained under three different working conditions. In addition, the prototype of " Sharp Eagle II” wave energy converter was tested on land and in real sea conditions. The experimental data have been collected, and the experimental data and simulation results were compared and validated. This work has laid a foundation for the design and application of the following " Sharp Eagle” series of devices.
Numerical Investigation on Severe Slugging in A Catenary Riser
Xiao-liang QI, Song GAO, Hai-yan GUO
2019, 33(5): 628-635. doi: 10.1007/s13344-019-0061-1
[Abstract](1667) [FullText HTML] (390)
Abstract:
A mathematical model is presented to study the main characteristics of severe slugging in a downward inclined pipeline followed by a catenary riser. In this model, both simplified transient model and phase distribution model are included so that the flow characteristics of each stage for severe slugging can be accurately reproduced, especially for blowout stage. The results show that the flow features of severe slugging can be simulated by the proposed mathematical model. A good agreement between the experimental data and the numerical results is observed. The model can predict the transient fluctuation of many respects, such as the superficial gas velocity at the bottom of the riser and the average velocity at the outlet of the riser.
