Abstract:
In offshore engineering, the phenomenon of free span often occurs, and the pipeline may have multiple free spans adjacent to each other, forming a multi-span pipeline. The interaction of different spans makes the structural vibration characteristics more complex, which may change the fatigue characteristics of the pipeline and affect the safety of the structure. In this paper, model tests were designed to explore the vortex-induced vibration (VIV) characteristics of multi-span pipelines and investigate the multi-span interaction mechanism. The experimental study mainly focused on the dynamic response of double-span pipelines, and further extended to triple-span pipelines, hoping that the results can be applied to more complex environment. The effects of span-length ratio, buried depth and axial force on VIV of the pipeline were investigated and discussed. The dynamic response of the pipeline varied with the span length. There was obvious interaction between different spans of multi-span pipelines, and the pipe-sediment interaction obviously affected the vibration characteristics of pipeline. The differences of pipeline burial depth and axial force changed the structural stiffness. With the increase of buried depth, the response amplitude presented a downward trend. The spanwise evolutions were asymmetric caused by the pipe-sediment interaction and multi-span interaction. The results can help to identify multi-span pipelines in engineering, and realize the prevention and control of free spans.
In offshore engineering, the phenomenon of free span often occurs, and the pipeline may have multiple free spans adjacent to each other, forming a multi-span pipeline. The interaction of different spans makes the structural vibration characteristics more complex, which may change the fatigue characteristics of the pipeline and affect the safety of the structure. In this paper, model tests were designed to explore the vortex-induced vibration (VIV) characteristics of multi-span pipelines and investigate the multi-span interaction mechanism. The experimental study mainly focused on the dynamic response of double-span pipelines, and further extended to triple-span pipelines, hoping that the results can be applied to more complex environment. The effects of span-length ratio, buried depth and axial force on VIV of the pipeline were investigated and discussed. The dynamic response of the pipeline varied with the span length. There was obvious interaction between different spans of multi-span pipelines, and the pipe-sediment interaction obviously affected the vibration characteristics of pipeline. The differences of pipeline burial depth and axial force changed the structural stiffness. With the increase of buried depth, the response amplitude presented a downward trend. The spanwise evolutions were asymmetric caused by the pipe-sediment interaction and multi-span interaction. The results can help to identify multi-span pipelines in engineering, and realize the prevention and control of free spans.
2023, 37(2): 190-203.
doi: 10.1007/s13344-023-0017-3
Abstract:
As key components connecting offshore floating production platforms and subsea imports, offshore flexible pipes play significant roles in oil, natural gas, and water injection. It is found that torsional failure is one of the failure modes of flexible pipes during transportation and laying. In this paper, a theoretical model (TM) of a flexible pipe section mechanics is established, in which the carcass layer and the pressure armor layer are equivalent to the orthogonal anisotropic layers due to its complex cross-section structure. The calculation results of the TM are consistent with those of a finite element model (FEM), which can accurately describe the torsional response of the flexible pipe. Subsequently, the TM and FEM are used to discuss the influence of boundary conditions on the torsional response. The structure of the flexible pipe is stable when twisted counterclockwise. However, limiting the top axial displacement can improve the axial and radial instability of the tensile armor layer when twisted clockwise. Finally, it is recommended that the flexible pipe can be kept under top fixation during service or installation to avoid torsional failure.
As key components connecting offshore floating production platforms and subsea imports, offshore flexible pipes play significant roles in oil, natural gas, and water injection. It is found that torsional failure is one of the failure modes of flexible pipes during transportation and laying. In this paper, a theoretical model (TM) of a flexible pipe section mechanics is established, in which the carcass layer and the pressure armor layer are equivalent to the orthogonal anisotropic layers due to its complex cross-section structure. The calculation results of the TM are consistent with those of a finite element model (FEM), which can accurately describe the torsional response of the flexible pipe. Subsequently, the TM and FEM are used to discuss the influence of boundary conditions on the torsional response. The structure of the flexible pipe is stable when twisted counterclockwise. However, limiting the top axial displacement can improve the axial and radial instability of the tensile armor layer when twisted clockwise. Finally, it is recommended that the flexible pipe can be kept under top fixation during service or installation to avoid torsional failure.
2023, 37(2): 204-217.
doi: 10.1007/s13344-023-0019-1
Abstract:
An analytical solution for long waves propagating over a submerged atoll is established. The atolls involved in this study are annular coral reefs with large lagoons in the middle, and the expression of the cross section is a trinomial function of the radial distance, i.e., h=ar2s−brs+h0, where s is the positive rational number. This analytical solution extends the theory by Wang et al. (2018) as s is no longer limited to s=2/m, where m is the positive integer. In addition, by adjusting the terrain parameters properly, the analytic solution can be degenerated to describe the wave propagation over topography with a hump or pit. According to the relationship between wave rays and wave energy, the distribution characteristics and formation mechanism of energy over the topography are expounded. When the lagoon is non-existent, all wave rays converge at the x-axis, which results in an abrupt amplification of the wave amplitude around the convergence point. When a lagoon is mounted on the top of the atoll, the rays are scattered due to the refraction of the lagoon, and only some rays converge at the symmetrical axis and the ridges on both sides, which results in the amplification of wave amplitudes in these areas.
An analytical solution for long waves propagating over a submerged atoll is established. The atolls involved in this study are annular coral reefs with large lagoons in the middle, and the expression of the cross section is a trinomial function of the radial distance, i.e., h=ar2s−brs+h0, where s is the positive rational number. This analytical solution extends the theory by Wang et al. (2018) as s is no longer limited to s=2/m, where m is the positive integer. In addition, by adjusting the terrain parameters properly, the analytic solution can be degenerated to describe the wave propagation over topography with a hump or pit. According to the relationship between wave rays and wave energy, the distribution characteristics and formation mechanism of energy over the topography are expounded. When the lagoon is non-existent, all wave rays converge at the x-axis, which results in an abrupt amplification of the wave amplitude around the convergence point. When a lagoon is mounted on the top of the atoll, the rays are scattered due to the refraction of the lagoon, and only some rays converge at the symmetrical axis and the ridges on both sides, which results in the amplification of wave amplitudes in these areas.
2023, 37(2): 218-231.
doi: 10.1007/s13344-023-0020-8
Abstract:
Offshore wind turbines (OWTs) suffer wind, wave and earthquake loads. The investigation of OWTs’ dynamic response under environmental loads is essential for structural safety assessment. The soil−structure interaction (SSI) significantly affects the responses of OWT under environmental loads. However, there is few systematic research about the difference in the dynamic response of different SSI models under environmental loads. In order to solve the problem, the OWT is modeled by shell element, and several SSI models are built. The wind, wave and earthquake loads are taken into account. Moreover, the dynamic response, fatigue and buckling analysis are performed by ANSYS. The results indicate that SSI cannot be ignored in the dynamic response of the OWT under wind and wave loads. The SSI can decrease the displacement response of the OWT by 19% under wind and wave loads and reduce the fatigue damage of the pile. Multi-layer SSI can strongly influence the OWT’s dynamic response under wind and wave loads or earthquake-only load. The vertical earthquake load increases the dynamic response in three directions. Besides, in order to simulate real environment, multi-layer SSI, soil damping and vertical SSI must be considered to evaluate the displacement response of the OWT under wind, wave and earthquake loads. The earthquake and gravity loads can cause more obvious response of the OWT than that of only wind and wave loads. The top and bottom of the tower are prone to occur buckling.
Offshore wind turbines (OWTs) suffer wind, wave and earthquake loads. The investigation of OWTs’ dynamic response under environmental loads is essential for structural safety assessment. The soil−structure interaction (SSI) significantly affects the responses of OWT under environmental loads. However, there is few systematic research about the difference in the dynamic response of different SSI models under environmental loads. In order to solve the problem, the OWT is modeled by shell element, and several SSI models are built. The wind, wave and earthquake loads are taken into account. Moreover, the dynamic response, fatigue and buckling analysis are performed by ANSYS. The results indicate that SSI cannot be ignored in the dynamic response of the OWT under wind and wave loads. The SSI can decrease the displacement response of the OWT by 19% under wind and wave loads and reduce the fatigue damage of the pile. Multi-layer SSI can strongly influence the OWT’s dynamic response under wind and wave loads or earthquake-only load. The vertical earthquake load increases the dynamic response in three directions. Besides, in order to simulate real environment, multi-layer SSI, soil damping and vertical SSI must be considered to evaluate the displacement response of the OWT under wind, wave and earthquake loads. The earthquake and gravity loads can cause more obvious response of the OWT than that of only wind and wave loads. The top and bottom of the tower are prone to occur buckling.
2023, 37(2): 232-246.
doi: 10.1007/s13344-023-0015-5
Abstract:
In this study, a morphodynamic numerical model is established with the Regional Ocean Modeling System (ROMS) to investigate the transient behavior of sand waves under realistic sea conditions. The simulation of sand wave evolution comprises two steps: 1) a regional-scale model is configured first to simulate the ocean hydrodynamics, i.e., tides and tidal currents, and 2) the transient behavior of sand waves is simulated in a small computational domain under the time-variant currents extracted from the large model. The evolution of sand waves on the continental shelf in the Beibu Gulf is specifically investigated. The numerical results of the two-year evolution of sand waves under normal sea conditions compare well with the field survey data. The transient behavior of sand waves in individual months shows that the sand waves are more stable in April and October than that in other months, which can be selected as the windows for seabed operations. The effects of sediment properties, including settling velocity, critical shear stress and surface erosion rate, on sand wave evolution are also analyzed. Then, the typhoon-induced currents are further superimposed on the tidal currents as the extreme weather conditions. Sand waves with the average wavelength generally have more active behavior than smaller or larger sand waves. The characteristics of the evolution of sand waves in an individual typhoon process are quite different for different hydrodynamic combinations. For the storm conditions, i.e., the real combination and maximum combination cases, the sand waves experience a significant migration together with a damping in height due to the dominant suspended sediment transport. For the mild conditions, i.e., the pure tidal current and minimum combination cases, the sand waves migrate less, but the heights continue growing due to the dominant bedload transport.
In this study, a morphodynamic numerical model is established with the Regional Ocean Modeling System (ROMS) to investigate the transient behavior of sand waves under realistic sea conditions. The simulation of sand wave evolution comprises two steps: 1) a regional-scale model is configured first to simulate the ocean hydrodynamics, i.e., tides and tidal currents, and 2) the transient behavior of sand waves is simulated in a small computational domain under the time-variant currents extracted from the large model. The evolution of sand waves on the continental shelf in the Beibu Gulf is specifically investigated. The numerical results of the two-year evolution of sand waves under normal sea conditions compare well with the field survey data. The transient behavior of sand waves in individual months shows that the sand waves are more stable in April and October than that in other months, which can be selected as the windows for seabed operations. The effects of sediment properties, including settling velocity, critical shear stress and surface erosion rate, on sand wave evolution are also analyzed. Then, the typhoon-induced currents are further superimposed on the tidal currents as the extreme weather conditions. Sand waves with the average wavelength generally have more active behavior than smaller or larger sand waves. The characteristics of the evolution of sand waves in an individual typhoon process are quite different for different hydrodynamic combinations. For the storm conditions, i.e., the real combination and maximum combination cases, the sand waves experience a significant migration together with a damping in height due to the dominant suspended sediment transport. For the mild conditions, i.e., the pure tidal current and minimum combination cases, the sand waves migrate less, but the heights continue growing due to the dominant bedload transport.
2023, 37(2): 247-257.
doi: 10.1007/s13344-023-0021-7
Abstract:
Freely movable wave energy converters (WECs) will greatly improve their adaptability to the marine environment. In this paper, a dual-mode oscillating water column (OWC) WEC with potential sailing capability is proposed. By opening and closing a gate on the side facing the waves, the WEC converts wave energy in the vertical duct (called VD mode) with low sailing resistance or in the backward bend duct (called BBD mode) with high sailing resistance. A small model and a medium model were designed and manufactured. The capture width ratio (CWR) of the small model in the two modes was experimentally studied. The CWR under bidirectional airflow and conversion characteristics under unidirectional airflow of the medium model in the BBD mode were obtained. Tests of the small model show that the peak CWR is 145.2% under regular waves and 90.1% under random waves in BBD mode, and in VD mode the peak CWR is about 60% of that in the BBD mode. Tests of the medium model show that the peak CWR is 228.96% under regular waves, the maximum wave-to-battery efficiency is 63.36% under regular waves and 30.17% under random waves, respectively.
Freely movable wave energy converters (WECs) will greatly improve their adaptability to the marine environment. In this paper, a dual-mode oscillating water column (OWC) WEC with potential sailing capability is proposed. By opening and closing a gate on the side facing the waves, the WEC converts wave energy in the vertical duct (called VD mode) with low sailing resistance or in the backward bend duct (called BBD mode) with high sailing resistance. A small model and a medium model were designed and manufactured. The capture width ratio (CWR) of the small model in the two modes was experimentally studied. The CWR under bidirectional airflow and conversion characteristics under unidirectional airflow of the medium model in the BBD mode were obtained. Tests of the small model show that the peak CWR is 145.2% under regular waves and 90.1% under random waves in BBD mode, and in VD mode the peak CWR is about 60% of that in the BBD mode. Tests of the medium model show that the peak CWR is 228.96% under regular waves, the maximum wave-to-battery efficiency is 63.36% under regular waves and 30.17% under random waves, respectively.
2023, 37(2): 258-271.
doi: 10.1007/s13344-023-0022-6
Abstract:
Experimental and numerical studies on the dynamic cable tension of a subsea module during semi-submerged hoisting tests are performed. The experiments are carried out in irregular waves and the time-domain numerical simulations are conducted using the software “Simulation of Marine Operations”. The numerical formulation is validated through a comparison with experimental test measurements. The effects of the significant wave height, spectral peak period, and wave direction on the dynamic effect in the main sling and sub-slings are then investigated numerically. The relationship between the wave parameters and the dynamic effect is identified in the time and frequency domains, enabling the allowable sea states to be partially specified. The extreme dynamic effects in all slings under different wave conditions are estimated by using cumulative distribution functions of the Gumbel distribution. The results show that it is reasonable to model a complex subsea module via slender elements and depth-dependent coefficients in simulations of offshore operations. Lowering operations are safer if the wave height is 1 m and the wave period is larger than 8 s because the wave steepness is sufficient for the maximum possible dynamic effect to remain below 0.9. The dynamic tension may decrease when the wave direction is approximately 150°. It is dangerous for subsea modules to encounter lateral waves while entering the water because large overloads and underloads in the extreme dynamic tension may cause snap loads to occur and the slings to become slack.
Experimental and numerical studies on the dynamic cable tension of a subsea module during semi-submerged hoisting tests are performed. The experiments are carried out in irregular waves and the time-domain numerical simulations are conducted using the software “Simulation of Marine Operations”. The numerical formulation is validated through a comparison with experimental test measurements. The effects of the significant wave height, spectral peak period, and wave direction on the dynamic effect in the main sling and sub-slings are then investigated numerically. The relationship between the wave parameters and the dynamic effect is identified in the time and frequency domains, enabling the allowable sea states to be partially specified. The extreme dynamic effects in all slings under different wave conditions are estimated by using cumulative distribution functions of the Gumbel distribution. The results show that it is reasonable to model a complex subsea module via slender elements and depth-dependent coefficients in simulations of offshore operations. Lowering operations are safer if the wave height is 1 m and the wave period is larger than 8 s because the wave steepness is sufficient for the maximum possible dynamic effect to remain below 0.9. The dynamic tension may decrease when the wave direction is approximately 150°. It is dangerous for subsea modules to encounter lateral waves while entering the water because large overloads and underloads in the extreme dynamic tension may cause snap loads to occur and the slings to become slack.
2023, 37(2): 272-287.
doi: 10.1007/s13344-023-0023-5
Abstract:
Since fibre-reinforced polymer (FRP) and stainless steel (SS) offer advantages of corrosion resistance and hybrid confinement, this study proposed a new type of composite column: sea sand concrete (SSC)-filled SS tubular columns with an inner FRP tube (CFSTFs) to help exploit abundant ocean resources in marine engineering. To study compressive behaviours of these novel members, eight CFSTFs and two SSC-filled SS tubular columns (CFSTs) were tested under axial compression. Their axial load−displacement curves, axial load−strain curves in SS or FRP tubes were obtained, and influences of key test parameters (the existence of glass FRP (GFRP) tubes, steel tube shapes, and GFRP tube thicknesses and diameters) were discussed. Further, specimen failure mechanism was analyzed employing the finite element method using ABAQUS software. Test results confirmed the excellent ductility and load-bearing capacity of CFSTFs. The existence of GFRP tubes inside can postpone SS tube buckling, and the content of inner FRP tubes, particularly increasing diameters, was found to improve compressive behaviours. GFRP contents helped develop the second elastic-plastic stage of the load−displacement curves. Furthermore, the bearing capacity of CFSTFs with a circular cross-section was approximately 26% higher than that with a square cross-section, and this difference narrowed with the increase in GFRP ratios.
Since fibre-reinforced polymer (FRP) and stainless steel (SS) offer advantages of corrosion resistance and hybrid confinement, this study proposed a new type of composite column: sea sand concrete (SSC)-filled SS tubular columns with an inner FRP tube (CFSTFs) to help exploit abundant ocean resources in marine engineering. To study compressive behaviours of these novel members, eight CFSTFs and two SSC-filled SS tubular columns (CFSTs) were tested under axial compression. Their axial load−displacement curves, axial load−strain curves in SS or FRP tubes were obtained, and influences of key test parameters (the existence of glass FRP (GFRP) tubes, steel tube shapes, and GFRP tube thicknesses and diameters) were discussed. Further, specimen failure mechanism was analyzed employing the finite element method using ABAQUS software. Test results confirmed the excellent ductility and load-bearing capacity of CFSTFs. The existence of GFRP tubes inside can postpone SS tube buckling, and the content of inner FRP tubes, particularly increasing diameters, was found to improve compressive behaviours. GFRP contents helped develop the second elastic-plastic stage of the load−displacement curves. Furthermore, the bearing capacity of CFSTFs with a circular cross-section was approximately 26% higher than that with a square cross-section, and this difference narrowed with the increase in GFRP ratios.
2023, 37(2): 288-298.
doi: 10.1007/s13344-023-0024-4
Abstract:
The present study establishes a simple numerical model for the coupled response of a steel catenary riser (SCR) subjected to coplanar vessel motion and vortex-induced vibration (VIV). Owing to the large deflection of the SCR, the geometric nonlinearity is considered in this model. The hydrodynamic force comprises the excitation force and hydrodynamic damping, where the excitation force that only exists when the non-dimensional frequency is located in the lock-in range, is associated with the VIV. The hydrodynamic force model is validated based on the published VIV test data. As for the seabed resistance at the touchdown zone (TDZ), integrated with an initial seabed trench, the hysteretic feature is modeled. Based on the model, the study emphasizes on the coupled response characteristics near the touchdown point (TDP) induced by coplanar vessel heave and VIV, and analyzes the sensitivity of the coupled response to the heaving amplitude and frequency. It is found that with the increase of the heave amplitude and frequency, the VIV can be obviously mitigated, but the heave-related response in the coupled analysis seems to be close to that in the heave-only simulation. Finally, the fatigue damage near TDP is parametrically investigated based on the separate analysis and the coupled analysis. The results demonstrate that the coupled effect plays a significant role in the fatigue assessment near TDP. Besides, the proportion of the coupled effect accounting for the total fatigue damage decreases with the increasing seabed stiffness, while increases with the increasing seabed trench depth.
The present study establishes a simple numerical model for the coupled response of a steel catenary riser (SCR) subjected to coplanar vessel motion and vortex-induced vibration (VIV). Owing to the large deflection of the SCR, the geometric nonlinearity is considered in this model. The hydrodynamic force comprises the excitation force and hydrodynamic damping, where the excitation force that only exists when the non-dimensional frequency is located in the lock-in range, is associated with the VIV. The hydrodynamic force model is validated based on the published VIV test data. As for the seabed resistance at the touchdown zone (TDZ), integrated with an initial seabed trench, the hysteretic feature is modeled. Based on the model, the study emphasizes on the coupled response characteristics near the touchdown point (TDP) induced by coplanar vessel heave and VIV, and analyzes the sensitivity of the coupled response to the heaving amplitude and frequency. It is found that with the increase of the heave amplitude and frequency, the VIV can be obviously mitigated, but the heave-related response in the coupled analysis seems to be close to that in the heave-only simulation. Finally, the fatigue damage near TDP is parametrically investigated based on the separate analysis and the coupled analysis. The results demonstrate that the coupled effect plays a significant role in the fatigue assessment near TDP. Besides, the proportion of the coupled effect accounting for the total fatigue damage decreases with the increasing seabed stiffness, while increases with the increasing seabed trench depth.
2023, 37(2): 299-311.
doi: 10.1007/s13344-023-0025-3
Abstract:
Numerical simulations of the non-spherical evolution of a pulsating bubble interacting with a stationary air bubble attached to a fixed structure were performed using a three-dimensional boundary integral method by implementing the mirror image method to simplify the processing of the numerical model. Code validation was accomplished by comparing the numerical results with the laboratory experimental data obtained in our previous study. Complex phenomena were observed, including three types of bubble jet forms, which depended strongly on the distance parameter with respect to the initial location of the bubble from the plate, the bubble strength parameter and the initial air bubble radius parameters. The results of the simulations provide detail insight into interesting bubble jetting phenomena, such as bubble splitting, jets moving away from the plate, and bubble shedding. The dimensionless distance parameter and the initial air bubble radius parameter play a major role in determining the shapes of two bubbles and the jetting direction. The air bubble strength parameter did not change the bubble jet direction but influenced the bubble shape. The detachment of the attached air bubble under oscillating bubble suction was easily observed for a small initial air bubble. These results showed that bubble jetting toward the plate was manipulated through the effect of attached air bubble, and that cavitation-based applications and underwater explosion bubble may benefit from this erosion mitigation approach.
Numerical simulations of the non-spherical evolution of a pulsating bubble interacting with a stationary air bubble attached to a fixed structure were performed using a three-dimensional boundary integral method by implementing the mirror image method to simplify the processing of the numerical model. Code validation was accomplished by comparing the numerical results with the laboratory experimental data obtained in our previous study. Complex phenomena were observed, including three types of bubble jet forms, which depended strongly on the distance parameter with respect to the initial location of the bubble from the plate, the bubble strength parameter and the initial air bubble radius parameters. The results of the simulations provide detail insight into interesting bubble jetting phenomena, such as bubble splitting, jets moving away from the plate, and bubble shedding. The dimensionless distance parameter and the initial air bubble radius parameter play a major role in determining the shapes of two bubbles and the jetting direction. The air bubble strength parameter did not change the bubble jet direction but influenced the bubble shape. The detachment of the attached air bubble under oscillating bubble suction was easily observed for a small initial air bubble. These results showed that bubble jetting toward the plate was manipulated through the effect of attached air bubble, and that cavitation-based applications and underwater explosion bubble may benefit from this erosion mitigation approach.
2023, 37(2): 312-322.
doi: 10.1007/s13344-023-0026-2
Abstract:
Waves play a major role in the ocean phenomena in the Gulf of Guinea (GoG). In order to reveal the spatial-temporal distribution characteristics and the propagation mechanism of waves from the South Atlantic Ocean to the GoG, 4 typical points located in mid-latitude of South Atlantic (14°30′W, 30°0′S), south of the GoG (10°30′W, 15°0′S), offshore of the GoG (0°0′, 0°0′) and near shore of the GoG (6°4′58.8″W, 4°3′36″S) are selected, and waves from Atlantic Ocean to GoG are simulated by using a two-layer-nesting wave numerical model SWAN (Simulating Waves Nearshore). The results show that the hybrid waves (waves hereafter) and the swells have strong relationship with local wind in Roaring Forties and at mid-latitude of South Atlantic Ocean, while there is no obvious correlation between waves and local winds in the GoG. Swells are generated in the South Atlantic Ocean and propagate into the GoG. 2D wave spectra at the four selected typical points are simulated. The spectral pattern and wave component structure indicate that the wave system in GoG is dominated by the S−SW swells generated from Roaring Forties and mid-latitude of South Atlantic, whether it is at maximum (2.2−2.8 m), medium (1.8−2.2 m) or minimum (1.2 m) significant wave height in the GoG during simulation period.
Waves play a major role in the ocean phenomena in the Gulf of Guinea (GoG). In order to reveal the spatial-temporal distribution characteristics and the propagation mechanism of waves from the South Atlantic Ocean to the GoG, 4 typical points located in mid-latitude of South Atlantic (14°30′W, 30°0′S), south of the GoG (10°30′W, 15°0′S), offshore of the GoG (0°0′, 0°0′) and near shore of the GoG (6°4′58.8″W, 4°3′36″S) are selected, and waves from Atlantic Ocean to GoG are simulated by using a two-layer-nesting wave numerical model SWAN (Simulating Waves Nearshore). The results show that the hybrid waves (waves hereafter) and the swells have strong relationship with local wind in Roaring Forties and at mid-latitude of South Atlantic Ocean, while there is no obvious correlation between waves and local winds in the GoG. Swells are generated in the South Atlantic Ocean and propagate into the GoG. 2D wave spectra at the four selected typical points are simulated. The spectral pattern and wave component structure indicate that the wave system in GoG is dominated by the S−SW swells generated from Roaring Forties and mid-latitude of South Atlantic, whether it is at maximum (2.2−2.8 m), medium (1.8−2.2 m) or minimum (1.2 m) significant wave height in the GoG during simulation period.
2023, 37(2): 323-332.
doi: 10.1007/s13344-023-0018-2
Abstract:
To analyze previous experimental data of suspended sediment concentration for silty sediment with different sediment particle sizes due to waves, a new stratification correction coefficient is presented. The suspended sediment concentration gradient and sediment particle diameter are selected as parameters. Furthermore, a diffusion coefficient model with a stratification effect over the whole water depth for silty sediment suspension under waves is developed. The comparison between the suspended sediment concentration calculated by the presented model and several groups of experimental data shows that the model can reasonably reflect the vertical distribution of silty sediment suspension. The stratification effect calculated by the present model decreases with an increase in the sediment particle diameter, which indicates that the model can be extended to describe the suspended sediment concentration of fine to medium sand when the near-bottom sediment concentration is not very high. Although the original model needs to be iteratively solved, the approximate method without iteration is recommended for applications when the near bottom sediment concentration is between 10 and 20 kg/m3 due to the small difference between the non-iterative and iterative solution for near bed layer suspended sediment concentration, which plays a major role in sediment transport.
To analyze previous experimental data of suspended sediment concentration for silty sediment with different sediment particle sizes due to waves, a new stratification correction coefficient is presented. The suspended sediment concentration gradient and sediment particle diameter are selected as parameters. Furthermore, a diffusion coefficient model with a stratification effect over the whole water depth for silty sediment suspension under waves is developed. The comparison between the suspended sediment concentration calculated by the presented model and several groups of experimental data shows that the model can reasonably reflect the vertical distribution of silty sediment suspension. The stratification effect calculated by the present model decreases with an increase in the sediment particle diameter, which indicates that the model can be extended to describe the suspended sediment concentration of fine to medium sand when the near-bottom sediment concentration is not very high. Although the original model needs to be iteratively solved, the approximate method without iteration is recommended for applications when the near bottom sediment concentration is between 10 and 20 kg/m3 due to the small difference between the non-iterative and iterative solution for near bed layer suspended sediment concentration, which plays a major role in sediment transport.
2023, 37(2): 333-342.
doi: 10.1007/s13344-023-0027-1
Abstract:
Recent damages to the box-like structures caused by wave slamming have made it necessary to study the impact problems of this kind of structure. This paper showed findings from numerical simulations of the rigid/elastic structures, aiming to gain insights into the characteristics of the problem. The results of the rigid cases showed the significance of air compressibility during the impact process, while the slamming phenomena became quite different without the effect. In the elastic cases, the trapped air made the structure vibrate at frequencies much smaller than its eigenfrequencies. Besides, the structural deformation made it easy for the trapped air to escape outwards, which weakened the air cushioning effect, especially at high impact velocities. The above analysis gives the results when the structural symmetry axis was vertical to the water (vertical impacts). In addition, the results were given when the axis was oblique to the water (oblique impacts). Compared with the vertical cases, the impact phenomena and structural response showed asymmetry. This work used the computational fluid dynamics (CFD) method to describe fluid motion and the finite element method (FEM) for the deformable structure. A two-way coupling approach was used to deal with the fluid−structure interaction in the elastic cases.
Recent damages to the box-like structures caused by wave slamming have made it necessary to study the impact problems of this kind of structure. This paper showed findings from numerical simulations of the rigid/elastic structures, aiming to gain insights into the characteristics of the problem. The results of the rigid cases showed the significance of air compressibility during the impact process, while the slamming phenomena became quite different without the effect. In the elastic cases, the trapped air made the structure vibrate at frequencies much smaller than its eigenfrequencies. Besides, the structural deformation made it easy for the trapped air to escape outwards, which weakened the air cushioning effect, especially at high impact velocities. The above analysis gives the results when the structural symmetry axis was vertical to the water (vertical impacts). In addition, the results were given when the axis was oblique to the water (oblique impacts). Compared with the vertical cases, the impact phenomena and structural response showed asymmetry. This work used the computational fluid dynamics (CFD) method to describe fluid motion and the finite element method (FEM) for the deformable structure. A two-way coupling approach was used to deal with the fluid−structure interaction in the elastic cases.
2023, 37(2): 343-352.
doi: 10.1007/s13344-023-0028-0
Abstract:
The present study aims to plumb blockage of the deep-sea mining pump transporting large particles with different shapes. A numerical work was performed through combining the computational fluid dynamics (CFD) technique and the discrete element method (DEM). Six particle shapes with sphericity ranging from 0.67 to 1.0 were selected. A velocity triangle is built with the absolute, relative, and circumferential velocities of particles. Velocity triangles with absolute velocity angles ranging from 90° to 180° prevail in the first-stage impeller. With declining sphericity, more particles follow the velocity triangle with absolute velocity angles ranging from 0° to 90°, which weakens the ability of particles to pass through the flow passage. Furthermore, the forces acting on the particles traveling in the impeller passage are analyzed. Large particles, especially non-spherical ones, suffer from high centrifugal force and therefore move along the suction surface of the impeller blades. Non-spherical particles undergo great drag force as a result of large surface area. The distribution of drag force angles is featured by two peaks, and one vanishes due to blockage. As particle sphericity declines, both magnitude and angle of the pressure gradient force decrease. Variation of the drag force and the pressure gradient force causes clockwise deflection of the centripetal force, resulting in deflection and elongation of particle trajectory, which increases the possibility of blockage.
The present study aims to plumb blockage of the deep-sea mining pump transporting large particles with different shapes. A numerical work was performed through combining the computational fluid dynamics (CFD) technique and the discrete element method (DEM). Six particle shapes with sphericity ranging from 0.67 to 1.0 were selected. A velocity triangle is built with the absolute, relative, and circumferential velocities of particles. Velocity triangles with absolute velocity angles ranging from 90° to 180° prevail in the first-stage impeller. With declining sphericity, more particles follow the velocity triangle with absolute velocity angles ranging from 0° to 90°, which weakens the ability of particles to pass through the flow passage. Furthermore, the forces acting on the particles traveling in the impeller passage are analyzed. Large particles, especially non-spherical ones, suffer from high centrifugal force and therefore move along the suction surface of the impeller blades. Non-spherical particles undergo great drag force as a result of large surface area. The distribution of drag force angles is featured by two peaks, and one vanishes due to blockage. As particle sphericity declines, both magnitude and angle of the pressure gradient force decrease. Variation of the drag force and the pressure gradient force causes clockwise deflection of the centripetal force, resulting in deflection and elongation of particle trajectory, which increases the possibility of blockage.
2023, 37(2): 353-353.
doi: 10.1007/s13344-023-0029-z
Abstract:
